Standard pickup area

2 m (radius), 360°

Maximum pickup area

3 m (radius), 360°

Pickup method

Stereo (automatic left/right channel setting, with 1 unit connected)

Monaural (with 2 to 4 units connected)

Microphone unit

Unidirectional electret condenser microphone (x4)

Number of connections

Maximum 4 microphones

Band frequency

150 Hz to 10 kHz

Maximum input sound pressure

110 dB spl

Sampling frequency

48 kHz

Delay time

1 ms (maximum)

Microphone cable connectors

2

Mute switch

Push and return switch

LED

2 colour LED (red, green) to indicate mute status

Red (mute on), Green (active), Orange (Start-up - blinks approx. 1 sec), Off (inactive)

General

Dimensions

120 mm (diameter) x 25 mm

Weight

Approx. 280 g

Cable length

Approx. 8.5 m

Operating temperature

0°C to 40°C

Operating humidity

10 - 90% (non condensation)
