Output

Output power capacity

2.7 KWatts / 3.0 kVA

Max Configurable Power (Watts)

2.7 KWatts / 3.0 kVA

Nominal Output Voltage

230V

Output Voltage Distortion

Less than 5%

Output Frequency (sync to mains)

50/60Hz +/- 3 Hz

Other Output Voltages

208, 220, 240

Topology

Line Interactive

Waveform type

Sine wave

Output Connections

(2) IEC Jumpers (Battery Backup)

(8) IEC 320 C13 (Battery Backup)

(1) IEC 320 C19 (Battery Backup)

Transfer Time

2-4 ms, 6ms typical: 10ms maximum

Input

Nominal Input Voltage

208V, 230V

Input frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

British BS1363A, IEC-320 C20, Schuko CEE 7/EU1-16P

Cord Length

2.44meters

Input voltage range for main operations

140 - 280V

Number of Power Cords

1

Other Input Voltages

220, 240

Transfer Time

2-4 ms

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time

3hour(s)

Replacement Battery

APCRBC117

Expected Battery Life (years)

3 – 5

RBC Quantity

1

Extendable Run Time

1

Battery Volt-Amp-Hour Capacity

738

Interface Port(s)

SmartSlot

Pre-Installed SmartSlot™ Cards

AP9631

Control panel

LED status display with On Line: On Battery: Replace Battery and Overload indicators, Multi-function LCD status and control console

Audible Alarm

Alarm when on battery: distinctive low battery alarm: configurable delays

Emergency Power Off (EPO)

Yes

Rack Height

2U

Dimension

85 x 432 x 667 mm

Weight

37.32kg
